Swann POE camera pin out

Recommended Posts

Typical POE is:





Blue/White POE +

White/Blue POE +


Brown/White POE -

White/Brown POE -


This is the standard so I would be surpised Swann would do anything other. Can you post a photo?

Share this post

Link to post
Share on other sites

If your Swann Camera has 8 wires.  Here is the wiring configuration to punch down to a Cat5 or 6 jack.

   Pin        T568B Scheme          Camera Wire


    1          Orange Stripe             Orange

    2          Orange                        Yellow

    3          Green Stripe               Green

    4          Blue                             Purple

    5          Blue Stripe                  Grey

    6           Green                          Blue

    7           Brown Stripe               Brown

    8           Brown                          White
