Lorex POE Camera Model MCNB2153 wiring diagram

Recommended Posts

Hi we have a Lorex POE Camera Model MCNB2153 but the female connector is fried i want to replaced it with a keystone but the color coding is different does anyone knows the color coding?

I managed to test the 4 colors but the others are fried. Thank you



here is the color of the ip cam wires

Lorex --- Cat5 Cable

White --- Brown

Orange --- Green White

Brown --- Orange White

Gray --- Brown White

Yellow ---

Purple ---

Blue ---

Green ---

Share this post


Link to post
Share on other sites

I had a similar problem and was able to determine the following:

It worked afterwards for my Lorex LND2152B camera.



PIN | LOREX Colors | T-568B Ethernet Colors

1-- | -----Brown----| ----Orange / White-----

2-- | -----Purple----| ----Orange--------------

3-- | -----Orange---| ----Green / White------

4-- | -----Yellow----| -----Blue----------------

5-- | -----Green-----| ----Blue / White--------

6-- | -----Blue-------| ----Green---------------

7-- | -----Grey-------| ----Brown / White-----

8-- | -----White------| ----Brown--------------

Share this post


Link to post
Share on other sites

I have a Lorex POE LNB4421-c POE Bullet. Can someone please give me the wiring diagram. The pins rusted and I need to crimp a new clip on the wire. Please help!! I called the company but tech support suggested i search Google.





my colors are:



Black

Red

Brown

purple

orange

yellow

blue

gray
