HD-SDI encoder for ACC6

Recommended Posts



has anyone used HD-SDI encoders with Avigilon Control Centre 6 or even 5.


ive had a search and come across this antrica ANT-35000A, the spec seems to fit the bill but only one channel


or this from TBS technology TBS2630 16 channel HD-SDI Video Encoder


got a site with around 40 existing cameras with 15 of them being PTZ


Cheers Andrew

Share this post

Link to post
Share on other sites

done some more digging


Euresys Picolo.net HD8R


they claim it has a ONVIF Profile S interface

Share this post

Link to post
Share on other sites

Hi Andrew


For the HD-SDI encoders You have mentioned, You will only be able to get rtsp stream. The Euresys encoder is profile s conformant and will be able to connect to both ACC5 and 6, as there are no difference in conformance, but the stream you can only record continously.

I'll recommend the Dahua pentaplex DVR XVR5808/16/32S which Support HDCVI/AHD/TVI/CVBS/IP video inputs. We use them with the Avigilon Control Center and it work's well. Just be aware of the You will only be able to rename 3 out of all channels in ACC(Dahua are on to fix this issue) and also be aware of that You need as many ACC license as the recorder have channels. 8 channels=8 licenses.


Best regards


Frank Kristensen

Elcon A/S Denmark
