Help With Farfisa replacement unit wiring

Recommended Posts



Just wondered if you any one would have some assistance.


I have purchased a replacement unit which is aFarfisa EX320 for the Farfisa 724N,


However i'm uncertain on the wiring configuration.


On the 724N there is 5 terminals (right image attached) and although not displayed the green and white wire goes up to to the lock on the 724N which is top left,


Could you please let me how the configuration should be when removing the wires from

the 724N and replacing them into the EX320. (left image attached)


Apologies as i thought this was a like for like job.


Many thanks for any help.
