techie996

Please HELP! Cameras stuck in CVBS mode

Recommended Posts

Okay, so I was playing around with the settings as my cameras would not display across the entire screen in 5MP@15/20 fps. It's a 1080p TV and just yesterday, it was displaying fine.

Anyway, I started experimenting with a few settings - went into the PTZ menu that you access from the camera's main screen (not the DVR's main menu) - and I changed it from AHD or TVI to CVBS.

Now both my cameras (as I changed both their default CVI setting to CVBS to check the aspect ratio) - are stuck in CVBS/ultra low resolution mode or SD. I can no longer access the PTZ menu. When I click on the main interface - nothing happens. I also noticed in the DVR's main menu PTZ settings (under "camera") that the Control Mode option is now greyed out. I can't even access that.



This is driving me absolutely nuts - my CCTV camera feed looks like it's more than 20 years old! I'm not even getting colour on one of the cams now. It's just stuck in CVBS mode. How do I restore it to TVI, AHD or CVI? I've literally tried experimenting with every single option in the menu.



Please HELP!! I have the Dahua dh-xvr5104hs-x1 with a Dahua camera and Pogo camera, both 5MP@20fps capable and 1080p@30 fps capable.

Share this post


Link to post
Share on other sites

Anyone, please? This is an emergency. I hope I won't have to manually reset stuff. I can't understand why it won't let me access the PTZ menu so I can go into "video output" to change it back to CVI or AHD/TVI.

Share this post


Link to post
Share on other sites

Hi  you can change camera format in camera settings on dvr and on some dahua you can click bottom left on each camera screen to alter format

are you also using a joystick

Share this post


Link to post
Share on other sites
35 minutes ago, tomcctv said:

Hi  you can change camera format in camera settings on dvr and on some dahua you can click bottom left on each camera screen to alter format

are you also using a joystick

There's no option in my DVR to change the format. It's only available through the PTZ menu. Which is no longer popping up to allow me to change it from cvbs to any of the HD formats like AHD or CVI, TVI.

No joystick. Mouse. There's not option on the bottom left of the screen to alter format. It's only accessible from the PTZ menu on the main camera screen. But that's just not displaying anymore for some odd reason. Camera is outputting an analogue/standard definition signal only. Looks dreadful.

If I change all the channels format from DVR menu to cvbs or auto, only then it displays the cameras in cvbs/SD resolution. Setting it to TVI or ahd, or CVI gives me a blank screen with the dahua logo.

Protocol is set to hdcvi3.0 but the control mode is greyed out. I can no longer change that.

Share this post


Link to post
Share on other sites

Ok. You can’t set the format via ptz control

all dahua unit have a manual mode

settings …..cameras……. Then channel format

tick all auto then save …… then switch off recorder and camera power supply …… switch recorder back on first ….. let it boot up before you switch on power supply for cameras

Share this post


Link to post
Share on other sites
8 hours ago, tomcctv said:

Ok. You can’t set the format via ptz control

all dahua unit have a manual mode

settings …..cameras……. Then channel format

tick all auto then save …… then switch off recorder and camera power supply …… switch recorder back on first ….. let it boot up before you switch on power supply for cameras

Thanks a lot for those tips. I have already tried that - the 'auto' settings makes the camera default to cvbs. I've tried restarting and switching off and on too.

I don't have a separate power supply for the cameras. When I turn on mains from the wall, the DVR and cameras turn on themselves.

I will try this step once again just to make sure. For some reason, the system is blocking me out of the PTZ menu where you get to select output format, make picture enhancements, white balance, etc. I saw one video where the guy said that setting it to cvbs or SD will no longer make the PTZ menu accessible and that you have to change settings manually.

But with channels set to auto, the only available resolutions are the cvbs ones, with the setting above the channel protocol greyed out - it should say hdcvi, but it's completely greyed out.

It's as if the cameras are now locked in cvbs mode and there's nothing in the DVR menu that lets me switch I back to CVI, TVI or AHD, for example.

If I manually set the channels to CVI or AHD, then I get the full resolution settings in the menu that the DVR can do - e.g. 1080p and 5mp, but then the camera screens are black with a question mark at the bottom.

It's as if the cameras are now just stuck in cvbs. I hope I don't have to get them reset or replaced.

Sorry for the long post, but I'm really distraught over this. Got both cameras and DVR very recently!

I'd attach photos but there is a 1.2mb limit!

Edit: the small power supply units are attached to the DVR, they're not independent. Do when they are both hooked up to the DVR, that's when they get juice. I  also tried powering up the DVR first waited for it to initialize and boot up, then hooked up cameras to even different ports. Same issue: they just default to cvbs.

I should mention that I have the latest firmware.

If it helps, I can email you screen shots of everything to help you better understand the setup and what could be causing the issue.

Thanks so much for providing prompt help!

Edit #2: sorry, you were right - there is a separate power plug for the DVR and cameras. I did what you said,but the only available resolutions are the SD ones no whatever what I set the channels to. Oddly, at bootup the DVR does switch to a 1080p Res like it always does. But the cameras are not picking up this Res. 960 x 480 is the highest res I'm seeing in the menu, even though last night I could see all the higher resolution and max bit rate of 6144, when the cameras were disconnected from the back of the unit.

Share this post


Link to post
Share on other sites

I've given up at this point and really require your expertise.tried the following again:

1. Set channels to Auto

2. Switched off DVR

3. Turned on DVR only and wait for bootup

4. Then connect camera power supply - sure enough, both screens indicated "loading"... But they show cvbs.

All 4 channels in Settings indicate a max Res of 960x480. I don't understand.. what happened to the other resolutions? *Irrespective of whether I choose AHD, CVI or Auto*

Instead of Auto, I also set the channels to AHD and CVI, then booted up the DVR, and then connected the cameras. No picture. It seems the camera can only pick up a signal via cvbs. This is beyond strange...

Share this post


Link to post
Share on other sites

The problem is that you have changed your camera into CVBS mode and therefore lost the control over co-ax/CAT5 function to access the OSD (On screen Display) menu.

Its a catch 22 because to fix the issue you need to undo what you have done but cant because you have no way to control the OSD menu through CVBS.

A factory default of the camera should sort this out. Some cameras have a hatch on them with a button inside that needs holding down for 60 seconds as power is introduced to the camera.

Others can be taken apart and may have said button on the mainboard. If none of these are available, some have two terminals that need to be bridged in order to short the camera and return it to factory settings.

Share this post


Link to post
Share on other sites
1 hour ago, CCTVDude88 said:

The problem is that you have changed your camera into CVBS mode and therefore lost the control over co-ax/CAT5 function to access the OSD (On screen Display) menu.

Its a catch 22 because to fix the issue you need to undo what you have done but cant because you have no way to control the OSD menu through CVBS.

A factory default of the camera should sort this out. Some cameras have a hatch on them with a button inside that needs holding down for 60 seconds as power is introduced to the camera.

Others can be taken apart and may have said button on the mainboard. If none of these are available, some have two terminals that need to be bridged in order to short the camera and return it to factory settings.

Thanks for the response. Catch 22 indeed!

Finally managed to track down the CCTV guy who installed it. He said the same without hesitation: that the cameras will be dismantled and taken to the manufacturer's service center to do a manual/hardware reset or factory reset, whatever they call it.

Don't know why this is even a thing .... If CVBS locks you out of the OSD menu and you can't change back to the HD modes, then why even have it as an option to begin with? Makes no sense 🤦🤦

If only I knew, would have never tinkered with it in the first place.



Share this post


Link to post
Share on other sites

Sorry but that is bull.


The dvr controls the cameras not the other way round

On 7/22/2021 at 7:44 AM, techie996 said:

All 4 channels in Settings indicate a max Res of 960x480.

You also might of set recorder out of range

( video output) which is also a setting in your menu having this set wrong will only allow you to use CVBS which is 960h

been dealing with dahua over 15 years and never had a camera that won’t change

and I know dahua does not reset cameras

and you will not find anyone on any forum sending cameras back to reformat



you also have a factory reset in your menu …. Use that ……. But disconnect all cameras first

Share this post


Link to post
Share on other sites

The video output setting is only accessible from the cameras' OSD menu. The xvr only allows me to select channel type and resolution. As you already know the camera OSD is no longer accessible as it is stuck in cvbs mode.

Maybe dahua do s not reset cameras but that is the only way to restore them to factory setting.

Hie can I set the recorde out of range? I haven't done anything that would cause it to do that.

Already did the factory reset twice. Once with cameras disconnected and then connected. All the available resolutions came back but when cameras got connected, it said "resolution will adjust automatically". And guess what? Defaulted back to cvbs @960h resolution. It's the only resolution and mode my cams are picking up.

The cameras have locked me out of the OSD menu and that is the only way to adjust video output. You seen to be having a hard time accepting that - don't know why you wrote it off as "bull".

I simply explained the options that are available to me now as a result of setting video output from CVI to CVBS - from the internal menu and not the dahua recorder menu. I've mentioned the model number at the start of the thread I think.

Share this post


Link to post
Share on other sites
7 hours ago, tomcctv said:

Sorry but that is bull.


The dvr controls the cameras not the other way round

You also might of set recorder out of range

( video output) which is also a setting in your menu having this set wrong will only allow you to use CVBS which is 960h

been dealing with dahua over 15 years and never had a camera that won’t change

and I know dahua does not reset cameras

and you will not find anyone on any forum sending cameras back to reformat



you also have a factory reset in your menu …. Use that ……. But disconnect all cameras first

Please check above reply

Share this post


Link to post
Share on other sites

Ok we don’t seam to be getting anywhere



your camera does not send data to recorder only it’s video output

your recorder controls camera via data

your installer must only be part time …….. Split between McDonald’s and installing

because sending cameras back to dahua for reset  is crap  ……. Posting to China you also have to pay post back to you adds up to 5 time the cost of a 5mp analog camera so makes no sense



3 hours ago, techie996 said:

Hie can I set the recorde out of range? I haven't done anything that would cause it to do that.

When you did a reset did the settings stay the same while cameras were not connected



there are many reasons and fixes to your problem

another one is your units password….. who set it up for you

Share this post


Link to post
Share on other sites
2 hours ago, tomcctv said:

Ok we don’t seam to be getting anywhere



your camera does not send data to recorder only it’s video output

your recorder controls camera via data

your installer must only be part time …….. Split between McDonald’s and installing

because sending cameras back to dahua for reset  is crap  ……. Posting to China you also have to pay post back to you adds up to 5 time the cost of a 5mp analog camera so makes no sense



When you did a reset did the settings stay the same while cameras were not connected



there are many reasons and fixes to your problem

another one is your units password….. who set it up for you

Would it be possible to discuss this on a FB messenger or WhatsApp call?
