Wifi transfer of 16ch live monitoring

[insmode 0]

Hi everyone,

Im establishing a cctv system in my own place.  I have ordered a dvr (DVR-216U-K2) that will be in my main building and I need to live stream (monitoring) from 35 meters far away another building.  Unfortunately I cant use any cable, I have to solve the problem by using wifi. There is a plasma monitor (Crea p32M-lw10n) that has only (scart,hdmi,s-video,PC rgb,video slots) in the bulding where I ll monitor the cameras.  I really need your advices about howto set this application. You may see the system structure drawing as attached. I need help at the red pointed area.

I dont wanna establish a computer, its gonna be hard to control if its being used something else or not. Also I will need to maintain time to time.

I thought using a mini android device but lcd monitor doesnt have usb slot, also Im not sure if its recognize the antenna I will plug for wifi. Also I havent used android mini device ever, so not sure if its sutable or not.

I think need a way that will add the plasma monitor into my lan(getting an ip), and  over the local ip catching the live stream.

Thanks



Edited May 24, 2019 by insmode
cant delete images............

[tomcctv 71]

Hi. Can you post the spec of your dvr.  It looks like you are using a hybrid which could limit you from the start

[Avek 0]

I have had the only experience with such cameras after I got a home security system. This was an Ajax system. It is a professional variant of the security system, nevertheless, it does not include cameras. So, the installers recommended me to buy another brand camera and they would be able to connect them to the system, and I would see the picture translation through the system app. I found good cameras on Amazon sales and the professionals did everything for me. If you still need to solve your issue, I can look for their contacts, and they will probably help you, they do not charge a lot.

[EddyH 0]

On 1/21/2021 at 9:56 AM, Avek said:

I have had the only experience with such cameras after I got a home security system. This was an Ajax system. It is a professional variant of the security system, nevertheless, it does not include cameras. So, the installers recommended me to buy another brand camera and they would be able to connect them to the system, and I would see the picture translation through the system app. I found good cameras on Amazon sales and the professionals did everything for me. If you still need to solve your issue, I can look for their contacts, and they will probably help you, they do not charge a lot.

Good time of day. I took cameras for ajax on ebay a couple of months ago. I didn't bother to look for good cameras, as it was only necessary for my old warehouse in the office. In any case, these cameras were perfectly suited to the security system and I was also able to use them well from my phone. So if you suddenly want to find cameras as cheap as possible, not for home, then I advise you to just look for options on the Internet. You will surely be able to find satisfactory cameras for yourself.
