Unbricking your Dahua IP camera (Tips, Tricks & Firmware)

Recommended Posts

I am starting this thread to capture a bunch of information in one spot to assist those with "bricked" cameras due failed firmware upgrades. I bought my first Dahua IP camera just a couple weeks ago. I was impressed & pretty happy with it, but upon reading about new capabilities in newer firmware, I decided to upgrade it. Then like many others on here, I lost access to the Web GUI and the camera was no longer functioning. I spent the last two weeks getting to know everything about these cameras and this thread will capture all this information. It will take me several weeks to document all the information so please be patient.



There are a variety of problems that I will try my best to explain and share the possible solutions. I have gotten pretty comfortable with these cameras and have purposely bricked them to various degrees of severity just to validate the recovery process. Most people "brick" their cameras trying to upgrade the firmware. This is not a serious issue and it can be corrected very easily. The camera runs an upgrade service on port 3800. The configTool always shows a default port of 37777 but this is not an issue as it can do the upgrade on port 3800 anyway. Change your port to 3800 and use a firmware file lsted below and you are back in business.



I will keep updating this post as I get more time to write all the details around recovery. I will also post links to over 40+ firmware files that and which cameras they will work with. It will take me a bit of time to capture all this information, so please be patient.







BRICKED CAMERA? How can you tell?



There are several types of "BRICKED" camera conditions and they have varying levels of severity and also varying levels of complexity for recovery. Most are simple and caused by bad firmware uploads. The worst will require a full rebuild of the partitions which load the kernel, software and all other data.



1. The first step in identifying the severity of your issue is to determine what still working on your camera. In order to do that, lets remove as many variables as possible to the troubleshooting process. If possible, connect the camera ethernet and PC ethernet on it's own switch and make sure that no vlan tagging is enabled on the switch.



Next, you need to figure out if the IP address is still reacheable. Ping the last known ip address. The default address for most cameras is 192.168.1.108.



If you don't know it you can use the arp/ping method to configure which adds as startic arp entry to a new ip address. (This feature is enabled on the camera by default)





2. Once you have a pingable IP, you need to know what services are still active on the camera. This can be done with a simple port scanner. I have added a link to below in tools.



3. Run the port scanner and record which ports are still open. In many cases port 23 and port 3800 will still be open. If this is your situation, it is a very simple fix. If no ports are open, you will need to do a full image load which is more complex.



The typical ports that you would see are:



23 - Telnet access

80 - Web User interface

443 - SSL

554 - Real time streaming port

3800 - Upgrade Deamon

5000 - UPnP

37777 - TCP Video streaming

37778 - UDP Video Streaming

42323 - Real time remote runner



Plus a whole bunch more of UDP ports and more TCP ports





REPAIR WITH PORT 3800



Download a step by step guide (DAHUA IP Camera Recovery v1.0.pdf) with screen prints @ http://tinyurl.com/lbl3up7



1A. If port 3800 is open you can connect with the Dahua Config tool (link below in tools). I tdefault to port 37777 but change it to 3800 as this port where the upgrade daemon is listening. Port 37777 is a redirect but it won't work if your firmware has failed.

Launch the config tool and click on login button. Type the IP address , username and password then port 3800.



Open a know working firmware file and upload to the camera.





1B. If port 3800 is not open, go to the next step to enable port 3800.



2. If you have telnet access, you can login with putty. Link to putty below in tools. The default Web UI password is admin / admin.



In older firmware the telnet account is root / vizxv

In newer firmware the telnet account is admin / 7ujMko0+"web UI password" ---> 7ujmko0admin





Once connected you can execute a ps command to see running processes. /usr/sbin/upgraded process is what listens on port 3800 for the firmware binary file.

There is also another copy in /var/tmp/



A useful tip for watching the upgrade process is to kill the "upgraded" process that is running and re-launch it in the foreground to watch the upgrade.



~#>ps



625 root 0:00 [mtdblock3]

630 root 0:00 [mtdblock4]

635 root 0:00 [mtdblock5]

772 root 0:00 [ubi_bgt7d]

776 root 0:00 [ubifs_bgt7_0]

790 root 0:00 /sbin/telnetd

798 root 0:00 [OSA_796_1]

860 root 0:00 syshelper elper 60

861 root 0:00 /usr/sbin/upgraded

869 root 0:00 [dsplogd]

870 root 0:00 [encode_guard]

889 root 0:00 [flush-ubifs_6_0]

923 root 3:29 ./VideoDaemon AEWB AF TVOUT



~#> kill -9 861

~#> /usr/sbin/upgraded



[OSA-APP] OSA Build on Apr 19 2014 at 09:55:50.

[OSA-APP] SVN NUM: 1609.



[libpdi] libpdi.so Build on Apr 19 2014 at 10:06:34.

[libpdi] SVN NUM: 13790.

[libpdi] Flashtype = 4,patSize = 100000,rwSize = 800,ersSize = 20000

22:52:46|[crypt] crypt_open ok!

Name: upgraded, bulid date: Apr 19 2014 09:17:58, svn: 255

[libpdi] >-------getSystemInfo------->

Fail to get env authcode!

[libpdi] Get authcode error

@@@@ buf = PZC4MU056W00XXX

22:52:52|[pdc] WARN (MISC_ioctl|493): Get SdCard cfg failed !

[libpdi] deviceType: IPC-HFW4300S-V2

[libpdi] processor: A5S88

[libpdi] hardwareVersion: 1.00

[libpdi] appAutoStart: 1

[libpdi] serialNumber: PZC4MU056W00XXX

[libpdi] processorCount: 1

[libpdi] deviceClass: IPC

[libpdi] noPtz: 1

[libpdi] noSdCard: 1

[libpdi] bandWidth: 48

[libpdi] <-------getSystemInfo-------<

UPGRADED_MSG: Can't Open /mnt/mtd/Config/passwd

UPGRADED_MSG: Login success!

UPGRADED_MSG: Kill 976 successful

[libpdi] Read: blkIndex: 1,pageIndex: 0,byteIndex: 0 ,fLag: ff

[libpdi] Write: blkIndex: 1,pageIndex: 0,byteIndex: 0 ,fLag: 0

UPGRADED_MSG: reset_watchdog

UPGRADED_MSG: Receive A4(alarm)

UPGRADED_MSG: reset_watchdog

UPGRADED_MSG: Receive A1(alive package)

UPGRADED_MSG: reset_watchdog

UPGRADED_MSG: Received : 29868252, FileSize : 29868252

UPGRADED_MSG: Download Complete

UPGRADED_MSG: DoDownLoad success!

UPGRADED_MSG: Flash init success

UPGRADED_MSG: hwid file success!

Fail to get env native!

UPGRADED_ERR: LINE: 1074: invalid file: Install.lua

UPGRADED_MSG: zip file total size: 40900220

[libpdi] >-------getSystemInfo------->

Fail to get env authcode!

[libpdi] Get authcode error

@@@@ buf = PZC4MU056W00XXX

22:53:10|[pdc] WARN (MISC_ioctl|493): Get SdCard cfg failed !

[libpdi] deviceType: IPC-HFW4300S-V2

[libpdi] processor: A5S88

[libpdi] hardwareVersion: 1.00

[libpdi] appAutoStart: 1

[libpdi] serialNumber: PZC4MU056W00XXX

[libpdi] processorCount: 1

[libpdi] deviceClass: IPC

[libpdi] noPtz: 1

[libpdi] noSdCard: 1

[libpdi] bandWidth: 48

[libpdi] <-------getSystemInfo-------<

UPGRADED_MSG: packet.name: SD6XXX, board.name: IPC-HFW4300S-V2

UPGRADED_MSG: packet.hardver: , board.hardver:

UPGRADED_MSG: packet.name: IPC-HX3XXX, board.name: IPC-HFW4300S-V2

UPGRADED_MSG: packet.hardver: , board.hardver:

UPGRADED_MSG: Verify version success



Header CRC Checking ... OK

Image Name: kernel.img

Image Type: kernel.img (gzip compressed)

Data Size: 2546876 B, Bytes = 2.43 MB

Load Address: 0XC80000

Data CRC Checking ... OK

Programing start at: 0XC80000



[libpdi] write update Flag

[libpdi] Read: blkIndex: 0,pageIndex: 0,byteIndex: 0 ,fLag: ff

[libpdi] Write: blkIndex: 0,pageIndex: 0,byteIndex: 0 ,fLag: 55

[libpdi] Flash_createPartionTab:6

[libpdi] Erase Partion: 6

[libpdi] FlashErase: addr= 0x0xc80000,blkNum:44, blkSize:0x20000,len:0x580000

<5>UBIFS: un-mount UBI device 2, volume 0

<5>UBIFS: un-mount UBI device 4, volume 0

Upgrade : Complete Total 6%...

Header CRC Checking ... OK

Image Name: partition-x.cramfs.img

Image Type: partition-x.cramfs.img (gzip compressed)

Data Size: 4160 B, Bytes = 0.00 MB

Load Address: 0X500000

Data CRC Checking ... OK

Programing start at: 0X500000



[libpdi] Flash_createPartionTab:3

[libpdi] Erase Partion: 3

[libpdi] FlashErase: addr= 0x0x500000,blkNum:8, blkSize:0x20000,len:0x100000

Upgrade : Complete Total 6%...

Header CRC Checking ... OK

Image Name: romfs-x.ubifs.img

Image Type: romfs-x.ubifs.img (gzip compressed)

Data Size: 7340096 B, Bytes = 7.00 MB

Load Address: 0X1200000

Data CRC Checking ... OK

Programing start at: 0X1200000



[libpdi] Flash_createPartionTab:7

[libpdi] Erase Partion: 7

[libpdi] FlashErase: addr= 0x0x1200000,blkNum:64, blkSize:0x20000,len:0x800000

Upgrade : Complete Total 24%...

Header CRC Checking ... OK

Image Name: pd-x.ubifs.img

Image Type: pd-x.ubifs.img (gzip compressed)

Data Size: 1966144 B, Bytes = 1.88 MB

Load Address: 0X940000

Data CRC Checking ... OK

Programing start at: 0X940000



[libpdi] Flash_createPartionTab:5

[libpdi] Erase Partion: 5

[libpdi] FlashErase: addr= 0x0x940000,blkNum:26, blkSize:0x20000,len:0x340000

Upgrade : Complete Total 28%...

Header CRC Checking ... OK

Image Name: user-x.ubifs.img

Image Type: user-x.ubifs.img (gzip compressed)

Data Size: 21233728 B, Bytes = 20.25 MB

Load Address: 0X2200000

Data CRC Checking ... OK

Programing start at: 0X2200000



[libpdi] Flash_createPartionTab:9

[libpdi] Erase Partion: 9

[libpdi] FlashErase: addr= 0x0x2200000,blkNum:204, blkSize:0x20000,len:0x1980000

Upgrade : Complete Total 80%...

Header CRC Checking ... OK

Image Name: custom-x.ubifs.img

Image Type: custom-x.ubifs.img (gzip compressed)

Data Size: 1966144 B, Bytes = 1.88 MB

Load Address: 0X600000

Data CRC Checking ... OK

Programing start at: 0X600000



[libpdi] Flash_createPartionTab:4

[libpdi] Erase Partion: 4

[libpdi] FlashErase: addr= 0x0x600000,blkNum:26, blkSize:0x20000,len:0x340000

Upgrade : Complete Total 85%...

Header CRC Checking ... OK

Image Name: web-x.ubifs.img

Image Type: web-x.ubifs.img (gzip compressed)

Data Size: 5505088 B, Bytes = 5.25 MB

Load Address: 0X1A00000

Data CRC Checking ... OK

Programing start at: 0X1A00000



[libpdi] Flash_createPartionTab:8

[libpdi] Erase Partion: 8

[libpdi] FlashErase: addr= 0x0x1a00000,blkNum:64, blkSize:0x20000,len:0x800000

Upgrade : Complete Total 99%... [libpdi] Read: blkIndex: 0,pageIndex: 1,byteIndex: 0 ,fLag: ff

[libpdi] Write: blkIndex: 0,pageIndex: 1,byteIndex: 0 ,fLag: aa

Upgrade : Complete Total 100%... UPGRADED_MSG: will reboot system

[libpdi] rebootSystem: i will reboot

[libpdi] Read: blkIndex: 1,pageIndex: 0,byteIndex: 0 ,fLag: ff

[libpdi] Write: blkIndex: 1,pageIndex: 0,byteIndex: 0 ,fLag: 0

[libpdi] pdi:system will reboot!!



Here you can see each partition being loaded wit the individual img files. I will write a quick how to on loading each one individually at a later time.



If you chose a valid firmware file, you will be back in working order. If you still have problems, repeat with another firmware file till you have a valid file. The IPC-HFW4300S-V2 is not natively compatible with all other 4300S firmware. I am in the process of writing a how to that explains how to over come this issue.



UNBRICK WITH UBOOT via SERIAL



NOTE: This section is coming soon... I'm gathering all the images I need for various camera types







OTHER USEFUL INFORMATION (to be sorted later)



The firmware consists of several images that are loaded into various partitions in flash in a UBI file system. You can load each partition separately if needed. More on this later.... (I'll put a guide together on flashing and recovering partitions)



Once you telnet into the camera, there are number of useful binaries in the user shell that can help correct and diagnose some of the problems people are experiencing. One of the helpful steps is to kill the /var/tmp/upgraded process and run it in the foreground so you can see what is going on and easily capture error messaged. The /var/tmp/upgraded process is what opens the port 3800 and allows you to connect to the camera with the config tool if your web services have failed. There is also another copy in usr/sbin/.



Also, in there is a command to reset all the parameters back to factory defaults (username, password, ip address back to 192.168.1.108 etc.) This can be accomplished with /sbin/clearparam.



Another issue that people run into is the constant reboot issue. This can be caused by a failed process. The main application which provides all the camera capabilities (web interface, streaming, etc.) is /usr/bin/sonia. This process is what makes most firmware different from version to version (sort of). There are also changes to the web partition which contains the web server pages that /usr/bin sonia hosts on port 80. The sonia process is invoked by a shell script in init.d and if the process is killed, the camera reboots after a few minutes. This has cause many people issues when trying to "unbrick" the camera since you only have a few minutes between reboots.



To stop the reboots you can update the flash. There is a parameter called appauto that tells the camera to auto start /us/bin/sonia. If you want the camera to start and not invoke the shell script that launches sonia, you need to set appauto to 0. This will stop the camera from rebooting when sonia is not running. This cam be accomplished by running '/sbin/appauto 0'. To turn it back on, just run /sbin/appauto 1. This writes the boot parameter in flash that the kernel reads before starting the process. You can check the current status of the appauto bootparameter with 'cat /proc/dahua/bootpara' It will only show what the parameter was when you booted up, so if you changes it you need to reboot to see the change in /proc/dahua/bootpara.



Realtime streaming URL - rtsp://192.168.1.108/cam/realmonitor?channel=1&subtype=0&proto=Onvif

You can change the subtype to 1 for the secondary stream also you can add user:password@ in front of the IP address if you have the permissions set requiring it.



You can use the HTTP API to configure some parameters that are not yet in the web UI. For instance, another member discovered he could enable NFS through the web UI in addition to the local SD card. This config is not possible through the web interface as you need to pick one or the other.

These documents details the API of Dahua video products (links provided to some of the versions below). Programmers or users can access and configure Dahua video products through the API. Every setting of the camera is available through the API whereas only a small number are available through the WEB interface. The document with version 1.10 is available with firmware version 2.0 and above. This document with version 1.20, 1.21, 1.22, 1.23,1.24,1,25,1,26,1,27,1,28 is available with firmware 2.210 and above.This document with version 1. 29 ,1.30, 1.31, 1.32, 1.33, 1.34, 1.35,

1.36 is available with firmware 2.210 and above.This document with version 1.37 is available with firmware 2.212, 2.4 and above.



I have also done a bit of testing around the tftp process that is invoked in u-boot that looks for upgrade_info_7db780a713a4.txt and failed.txt. I think with a little more work, I'll figure out if there is a recovery method using tftp without serial access. This would be necessary if you lose telnet access and need to rebuild the kernel partition that hosts telnetd.







Tools



DAHUA IP Camera Recovery v1.0.pdf....................... http://tinyurl.com/lbl3up7

Port Scanner .................................................. http://tinyurl.com/q53pojg

Putty .............................................................. http://tinyurl.com/lvbbmsq

Tftp Server ..................................................... http://tinyurl.com/m46wnhe





Dahua Docs & Tools



DAHUA_HTTP_API 1.0 .pdf ................................................ http://tinyurl.com/lb43lga

DAHUA_HTTP_API_1.23.pdf ................................................ http://tinyurl.com/lrwye3k

DAHUA_HTTP_API_FOR_IPC 1.28.pdf ........................................ http://tinyurl.com/kskrcay

DAHUA_HTTP_API_FOR_IPC&SD-V1.36.pdf .................................... http://tinyurl.com/mooccf9

DAHUA_HTTP_API_FOR_IPC&SD-V1.37.pdf .................................... http://tinyurl.com/kvyddfp

DAHUA_HTTP_API_FOR_DVR_V1.29.pdf ....................................... http://tinyurl.com/klc72tr



General_ConfigTool_Eng_V1.0.5.R.120428.zip ........................ http://tinyurl.com/mwlzbb3

General_ConfigTool_Eng_V1.06.1.T.120807.zip ........................ http://tinyurl.com/leudphu

General_ConfigTool_Eng_V1.07.2.R.130304.zip ....................... http://tinyurl.com/obs5ud7

General_ConfigTool_Eng_V1.07.3.R.130701.zip ....................... http://tinyurl.com/o6p628f <---- Use this one

General_ConfigTool_Eng_V2.00.0.R.140410.zip ........................ http://tinyurl.com/nbqtgev





Firmware Files



Firmware files are grouped by camera type and video signal (NTSC --> Eng_N / PAL --> Eng_P / or BOTH --> Eng_NP)

Files are ordered by version number with the latest Firmware in blue.

Files with DH_ prefix are DAHUA direct firmware files and those with General_ prefix are general release for OEM cameras but I've had good luck with both.





DH_IPC-HX1100_Eng_NP_V2.210.0000.3.R.20140416.bin .................................................. http://tinyurl.com/m2jf3qv





General_IPC-HX3(2)XXX_Eng_N_V2.210.0001.0.R.20130517.bin ............................................... http://tinyurl.com/q98zg9x

General_IPC-HX3(2)XXX_Eng_P_V2.210.0001.0.R.20130517.bin ................................................ http://tinyurl.com/nekapn3

General_IPC-HX3(2)XXX_Eng_NP_V2.210.0001.0.R.20130517.bin ............................................. http://tinyurl.com/p59ym6z

General_IPC-HX3(2)XXX_Eng_P_V2.211.0000.0.R.20130726.bin ................................................ http://tinyurl.com/my54r9z

General_IPC-HX3(2)XXX_Eng_N_V2.212.0000.0.R.20131206.bin ............................................... http://tinyurl.com/lrvtm2z

General_IPC-HX3(2)XXX_Eng_P_V2.212.0000.0.R.20131206.bin ................................................ http://tinyurl.com/n9rv23n

General_IPC-HX3(2)XXX_Eng_N_V2.212.0001.0.R.20131224.bin ............................................... http://tinyurl.com/l5kg2d9

General_IPC-HX3(2)XXX_Eng_P_V2.212.0001.0.R.20131224.bin ................................................ http://tinyurl.com/q6c2gox

DH_IPC-HX3(2)XXX_Eng_NP_8M_V2.212.0000.4.R.20140307.bin ............................................... http://tinyurl.com/mnzx33h

DH_IPC-HX3(2)XXX_Eng_NP_8M_V2.212.0000.5.R.20140326.bin ............................................... http://tinyurl.com/ke285w5

DH_IPC-HX3(2)XXX_Eng_NP_8M_V2.212.0000.6.R.20140419.bin ............................................... http://tinyurl.com/mllzcox

General_IPC-HX3(2)XXX_Eng_P_V2.420.0000.0.R.20140414.bin ................................................ http://tinyurl.com/nftaogy

DH_IPC-HX3(2)XXX_Eng_N_V2.420.0000.0.R.20140414.bin .................................................... http://tinyurl.com/ma5q64d





General_IPC-HX5(4)XXX_Eng_P_V2.210.0000.2.R.20130821.bin ................................................. http://tinyurl.com/pdcdmdk

General_IPC-HX5(4)XXX_Eng_N_V2.210.0000.4.R.20130911.bin ........................................................ http://tinyurl.com/pdoxjzj

General_IPC-HX5(4)XXX_Eng_P_V2.210.0000.9.R.20131217.bin ........................................................ http://tinyurl.com/p3g4t54

General_IPC-HX5(4)XXX_Eng_N_V2.210.0000.10.R.20140111.bin ...................................................... http://tinyurl.com/mnjpd79

General_IPC-HX5(4)XXX_Eng_P_V2.210.0000.12.R.20140225.bin ...................................................... http://tinyurl.com/nssnph6

DH_IPC-HX5(4)XXX_Eng_NP_V2.210.0000.12.R.20140225.bin ..................................................... http://tinyurl.com/lcjr8xv

DH_IPC-HX5(4)XXX_Eng_NP_V2.210.0000.16.R.20140421.bin ..................................................... http://tinyurl.com/k67gu9u

DH_IPC-HX5(4)XXX_Eng_NP_V2.210.0000.18.R.20140429.bin .................................................... http://tinyurl.com/n779scx

General_IPC-HX5(4)XXX_Eng_N_V2.210.0000.21.R.20140613.bin ...................................................... http://tinyurl.com/qd2thhe

General_IPC-HX5(4)XXX_Eng_P_V2.210.0000.21.R.20140613.bin ...................................................... http://tinyurl.com/p8q75b4

General_IPC-HX5(4)XXX_Eng_N_V2.400.0000.0.R.20131231.bin ........................................................ http://tinyurl.com/kmd7hu9

DH_IPC-HX5(4)XXX_Eng_N_Stream3_V2.420.0000.0.R.20140419.bin .................................................. http://tinyurl.com/mb75g2n

DH_IPC-HX5(4)XXX_Eng_P_Stream3_V2.420.0002.0.R.20140621.bin ............................................ http://tinyurl.com/laj29k5

General_IPC-HX5(4)XXX_Eng_N_Stream3_V2.420.0000.0.R.20140419.bin ......................................... http://tinyurl.com/mzw85fz

General_IPC-HX5(4)XXX_Eng_P_Stream3_V2.420.0000.0.R.20140419.bin ......................................... http://tinyurl.com/ov6krph

General_IPC-HX5(4)XXX_Eng_P_Stream3_P2P_V2.420.0000.0.R.20140419.bin ................................. http://tinyurl.com/oxgblkq

General_IPC-HX5(4)XXX_Eng_N_Stream3_V2.420.0002.0.R.20140621.bin ......................................... http://tinyurl.com/kejg3fv

General_IPC-HX5(4)XXX_Eng_P_Stream3_V2.420.0002.0.R.20140621.bin ......................................... http://tinyurl.com/pfmevdu

General_IPC-HX5(4)XXX_Eng_N_Stream3_V2.420.0003.0.R.20140930.bin ............................................... http://tinyurl.com/kchslos

General_IPC-HX5(4)XXX_Eng_N_V2.420.0003.0.R.20140930.bin ........................................................ http://tinyurl.com/ok4f8fx

General_IPC-HX5(4)XXX_Eng_N_Stream3_V2.420.0005.0.R.20141205.bin .............................................. http://tinyurl.com/qbrfg3k

General_IPC-HX5(4)XXX_Eng_P_Stream3_V2.420.0005.0.R.20141205.bin ......................................... http://tinyurl.com/ot99vgw





DH_IPC-HX8XXX_Eng_NP_V2.400.0000.2.R.20140506.bin .......................................................... http://tinyurl.com/lbar98x







I will also post the bare metal img files when I get some time which contain the firmware and all the img files including the update.img that can be used for serial recovery.



I have just started the process of uploading firmware... There are much more to come as well as many more camera models.

Also if you have any you want to share please PM me what you have and where I can link them to this thread.



Thanks to Euly for sharing firmware files!



___________________________________



IMPORTANT NOTE FOR IPC-HFW4300S-V2 CAMERAS



The new camera appears to have differences (a few that I already found) that makes some of the general firmware incompatible with them. I have found a workaround, but it is complex. I will try to summarize it in a separate thread in the following weeks. I will also repackage the newest firmware files in versions that will work for the V2 cameras. Stay tuned! In the meantime, you can use General_IPC-HX5(4)XXX_Eng_N_V2.210.0000.21.R.20140613.bin or the PAL equivalent to recover your camera.





Well, that's all I have time to share for now, but I'll do my best to put together a comprehensive guide to the inner workings of these cameras and a guide to unbrick in any failed software situation.



Thanks and take care.



Rob

Edited by Guest

Share this post


Link to post
Share on other sites

A week ago, I bricked a IPC-HFW4300S-V2 after upgrading with standard firmware. I wound up RMA'ing it because I couldn't connect to the GUI. I didn't know I could recover it, even though my router could see it, but I'm glad cctv_007 is developing this info to help other people.



From the information I've read on here, it sounds like the V2 inferior to the standard version, is this true?

Share this post


Link to post
Share on other sites

Starting to document the U-Boot environment and the Serial interfaces on the various cameras. Using a USB to TLL interface,, you can connect to the cameras and use the TFTP process to load partition images files or upgrade.img to load firmware to the camera. You need only connect the TX, RX and GND connections to communicate with the serial interface. The serial config is 115200, 8, N, 1, N.



Here is the serial interface on the IPC-HFW4300S. It seems they opted to leave out a built in connector. I suspect this is because of the new TFTP recovery process with the Magic string.









I'll post the photos of the other cameras with the pin-outs once I get around to snapping some pictures.


Edited by Guest

Share this post


Link to post
Share on other sites

Here is the serial output from the U-Boot process. As you can see the TFTP process looks for a file called upgrade_info_7db780a713a4.txt When it reads the contents it's looking for a "Magic String". With this string, I suspect another TFTP process would then load the firmware files thus allowing a bare metal install of the firmware. When I get some time I'll work on trying to extract this info from the u-boot partition.







At first boot, you have a second to interrupt the boot process and jump to the command line. You need to press and hold the * key (the one on the number pad) to interrupt the boot process.







From there you can run >printenv to get a look at the env variables







What's interesting on this particular camera is that the server IPs are all set including variables for autolip and autosip (which are likely tied to the TFTP recovery process and magic string)





The HWID string is used during process to validate that the firmware is compatible.



Also interesting are all the variables used to load various parts of the firmware.



da=tftp 0xc2000000 dhboot.bin.img; flwrite; tftp dhboot-min.bin.img;nand protect off;flwrite;nand pro t on

dr=tftp 0xc2000000 romfs-x.ubifs.img; flwrite

dk=tftp 0xc2000000 kernel.img; flwrite

du=tftp 0xc2000000 user-x.ubifs.img; flwrite

dw=tftp 0xc2000000 web-x.ubifs.img; flwrite

ds=tftp 0xc2000000 dsp-x.ubifs.img; flwrite

dc=tftp 0xc2000000 custom-x.ubifs.img; flwrite

dt=tftp 0xc2000000 data-x.ubifs.img; flwrite

df=tftp 0xc2000000 fpga.img; flwrite

up=tftp 0xc2000000 update.img; flwrite

tk=tftp 0xc2000000 uImage; bootm



You can execute the command run up which will tftp update.img from your serverip address specified in the env variables. You can also load individual files. I've successfully loaded firmware with this method and will post screen prints of the process later.



Here, you can also modify the kernel boot arguments, as well as see which address space the boot command loads from.




Edited by Guest

Share this post


Link to post
Share on other sites

Thank you SOOOOO much for this post, you saved me from myself. WHEW. I know just enough to get myself in trouble but your instructions were enough to get my camera working again. After several firmware attempts, and getting my camera stuck in a reboot loop I finally just tried the firmware you list at the bottom of the post and my camera was back up and running again.



What's weird is that a couple of months ago I purchased a couple other Dahua IPC-HFW4300S v2 cameras and they both came with:



Software Version2.420.0003.0.R, build : 2014-09-30

WEB Version3.2.1.223527

ONVIF Version2.4.1



Which prompted me to try and update the 3rd one I just received today. No dice and extreme panic until I found your extremely helpful post here.



Thank you so much for your work on these cameras and hopefully you're able to figure out how to get the latest firmware working on all the IPC-HFW4300S v2 cameras.



Thanks again,

Paul

Share this post


Link to post
Share on other sites

Here is the simplest way I know to-date to load the newest firmware on IPC-HFW4300S-V2 and other Chinese Dahua cameras ordered on AliExpress.... I'm still working on a permanent fix, but I've had many emails about this so I thought I'd post a quick update.



1. Use the config tool or web UI to load the newest firmware (General_IPC-HX5(4)XXX_Eng_N_Stream3_V2.420.0005.0.R.20141205.bin)

2. Your camera will appear bricked (no web ui) but the only issue preventing it from working is the language settings (which prevents sonia from loading)

3. Login into the camera with Telnet (user: admin / password: 7ujMko0{web ui password}

4. You will need to perform a few edits, so you need to make mounts read/write

\> mount -o remount rw /usr

\> mount -o remount rw /mnt/custom



5. Rename files

\> mv /usr/data/Strings/English.txt /usr/data/Strings/SimpChinese.txt

\> mv /mnt/custom/English.txt /mnt/custom/SimpChinese.txt



6. Edit files with vi ---> /usr/data/Strings/i18n & /mnt/custom/i18n. Change the following:



"DefaultLanguage" : "English", ------> SimpChinese

"DefaultVideoStandard" : "NTSC",

"DevStringFiles" : [ "StringsEn.txt" ],

"HTMLStringFiles" : [ "webEN.json" ],

"Languages" : [ "English" ], ------> SimpChinese

"VideoStandards" : [ "NTSC" ],

"WebStringFiles" : [ "webEN.lang" ]



(Tips for using vi: press "i" for insert then ESC when done editing, then type :w to write then type :q! to exit)



type reboot to restart the camera and you will have a working New English firmware. These changes will need to be repeated if you upgrade to another firmware since these partitions are erased an re-flashed during an upgrade.



I'm really trying to get to the root cause of why the camera seems hard-coded to Chinese and I will update as I uncover more information.



Thanks,

Rob

Edited by Guest

Share this post


Link to post
Share on other sites

It would be really helpful if at the end of this, you created a pdf for download. Thanks for pulling all of this together!

Share this post


Link to post
Share on other sites

Great post!. Maybe you can help me, I'm looking for the lastest DH-IPC-F625P firmware, but i can't find it. I'll really appreciate it.

Share this post


Link to post
Share on other sites

Hello there! Thanks for all the information regarding the HFW-4300S v2.



I inadvertently screwed up my admin password for most of the cameras that I have (8 in total), but I have access to the admin interface using the 888888 user. Will flashing the cameras with new firmware reset the passwords/enable me to use telnet? I'm currently on 2.420.0000.0.R, build : 2014-04-19



Thanks!

-EP

Share this post


Link to post
Share on other sites

Hey Folks, hope someone can help me...



I have an English NTSC Dahua IPC-HDBW2300R-Z dome camera with firmware 2.420.0000.3.R, build : 2014-07-23 and while the camera works well standalone, good integration with a VMS such as ExacqVision is problematic, as frames are dropped during recordings. My other two Dahua cameras (IPC-HDB4300C & IPC-HFW4300S) both on firmware 2.420.0000.0.R, build : 2014-04-19 are working and recording perfectly in the VMS.



I did a test and upgraded my IPC-HFW4300S to firmware 2.420.0005.0.R.20141205, and interestingly it exhibited the same recording issues as the IPC-HDBW2300R-Z until I put it back on 2.420.0000.0.R.20140419. It must be that the VMS is not compatible with newer firmware than the base v2.420.0000



I therefore attempted to also downgrade the IPC-HDBW2300R-Z but none of the "IPC-HX3(2)XXX_Eng_N" or "IPC-HX5(4)XXX_Eng_N" firmwares I tried worked. Does anyone have/know of any alternate firmware for the IPC-HDBW2300R-Z camera?



Thanks in advance.

Share this post


Link to post
Share on other sites

Have you tried adjusting your I-Frame interval?



Hey Folks, hope someone can help me...



I have an English NTSC Dahua IPC-HDBW2300R-Z dome camera with firmware 2.420.0000.3.R, build : 2014-07-23 and while the camera works well standalone, good integration with a VMS such as ExacqVision is problematic, as frames are dropped during recordings. My other two Dahua cameras (IPC-HDB4300C & IPC-HFW4300S) both on firmware 2.420.0000.0.R, build : 2014-04-19 are working and recording perfectly in the VMS.



I did a test and upgraded my IPC-HFW4300S to firmware 2.420.0005.0.R.20141205, and interestingly it exhibited the same recording issues as the IPC-HDBW2300R-Z until I put it back on 2.420.0000.0.R.20140419. It must be that the VMS is not compatible with newer firmware than the base v2.420.0000



I therefore attempted to also downgrade the IPC-HDBW2300R-Z but none of the "IPC-HX3(2)XXX_Eng_N" or "IPC-HX5(4)XXX_Eng_N" firmwares I tried worked. Does anyone have/know of any alternate firmware for the IPC-HDBW2300R-Z camera?



Thanks in advance.

Share this post


Link to post
Share on other sites
Here is the simplest way I know to-date to load the newest firmware on IPC-HFW4300S-V2 and other Chinese Dahua cameras ordered on AliExpress.... I'm still working on a permanent fix, but I've had many emails about this so I thought I'd post a quick update.



Is there any chance that using a Chinese version of the config tool would make a difference? I had some l luck a year ago when I purchased some Dahua cameras from Ali Express. Upgrading the Eng firmware seemed to brick my cameras, until I tried switching from the English config tool and using the Chinese version (the gui buttons were all in the same place). I'm not sure why, but the Chinese configtool solved my problems.



I posted on Cam-It at the time. Not sure I helped anyone though. Just in case, I wanted to share.



http://www.cam-it.org/index.php?topic=6510.msg40893#msg40893



I got a 404 error trying to access camera, so I turned off power, restarted, and the camera showed up fine, no problems. So I tried installing the firmware again, and it failed again. Except this time, the camera was not fine. I could not access it by IP address, it gave me a blank white page "Error 404 Not Found" that came from the camera. No matter what I tried, it seemed totally bricked.



But then I tried this Chinese tool I have, basically the same as my other Config Tool, so I was able to guess at the Chinese buttons. It was able to connect to the camera, install the new firmware, and fixed the entire issue! Everything is back to normal for me, and my camera has the new firmware installed.



So I'm wondering, did I just get lucky, or do I have some magical Chinese tool that overrides regional settings or something-- that can help out other people who bricked with wrong firmware? What I used is called General_ConfigTool_Chn_V1.06.0.R.120628

Share this post


Link to post
Share on other sites

What a really useful post. Thanks a lot for taking the time to document this in such detail.



I have one question tho' - does anyone know where I can find out exactly what new features are offered in the 2.4.X firmware that are not in 2.212 ? I'd like to know if it's worth the bother to do the upgrade or not.



-- Chris

Share this post


Link to post
Share on other sites
Hello there! Thanks for all the information regarding the HFW-4300S v2.



I inadvertently screwed up my admin password for most of the cameras that I have (8 in total), but I have access to the admin interface using the 888888 user. Will flashing the cameras with new firmware reset the passwords/enable me to use telnet? I'm currently on 2.420.0000.0.R, build : 2014-04-19



Thanks!

-EP

I don't know about re-loading the firmware, but if you need to re-set the passwords, you can use the clearparam command as described in the opening post.



telnet into the camera, then type



/sbin/clearparam



This will do a 'factory reset' for all of the camera parameters - it will clear any user accounts that you may have created, and it will restore the camera default settings (passwords, ip addresses, overlays, etc).



When I ran this the process seemed to hang (as it has changed the camera ip address, and so the telnet session was mangled). But after waiting for the camera to re-appear as 192.168.1.108 I was able to access the GUI using admin and the default admin password.





-- Chris

Share this post


Link to post
Share on other sites
Hello there! Thanks for all the information regarding the HFW-4300S v2.



I inadvertently screwed up my admin password for most of the cameras that I have (8 in total), but I have access to the admin interface using the 888888 user. Will flashing the cameras with new firmware reset the passwords/enable me to use telnet? I'm currently on 2.420.0000.0.R, build : 2014-04-19



Thanks!

-EP

I don't know about re-loading the firmware, but if you need to re-set the passwords, you can use the clearparam command as described in the opening post.



telnet into the camera, then type



/sbin/clearparam



This will do a 'factory reset' for all of the camera parameters - it will clear any user accounts that you may have created, and it will restore the camera default settings (passwords, ip addresses, overlays, etc).



When I ran this the process seemed to hang (as it has changed the camera ip address, and so the telnet session was mangled). But after waiting for the camera to re-appear as 192.168.1.108 I was able to access the GUI using admin and the default admin password.





-- Chris





Unfortunately, since I changed the Admin account password to a password I cannot recall, I can't enter the SSH/Telnet area to run the /sbin/clearparam command...



-EP

Share this post


Link to post
Share on other sites

Unfortunately, since I changed the Admin account password to a password I cannot recall, I can't enter the SSH/Telnet area to run the /sbin/clearparam command...



-EP

The telnet command does not use the users / passwords that are used to access the gui. The telnet command only works with root / vizxv .





-- Chris

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!

Register a new account

Sign in

Already have an account? Sign in here.

Sign In Now

×
