Hello All, I could use some advice before I take this project on if it’s even possible. My client has a HikVision (model ds-7216HGHI-SH) DVR. They need two coax cameras fixed that are about 4000+ feet from the country club house for a golf course. They initially had a direct fiber run from the club house but the fiber broke somewhere underground. I wouldn't be able to fix that because it was a direct bury and the layout of the course now. They have a little tennis house around 2000 feet away from where the cameras are located. In that tennis house is a switch and fiber optic cable (see pic) that was trenched from the country club network to tennis house. What I wanted to know is this even possible? My installment thought processes is: 1. Convert the two coax cameras to fiber optic cable OR 1a. Convert the two coax to IP then to fiber. Not sure if you could even convert coax to fiber. Category to fiber yes. 2. Run fiber to the tennis building 3. Convert fiber to Ethernet Cat 6 4. Install Cat 6 into an open port on the switch that runs back to the country club network. 5. Come out of switch in country club network and convert it to coax and into the HikVision DVR The known… Might need to put power on the pool where the cameras are and a waterproof box to store the conversion stuff. I can’t fix the old fiber because they don’t want to. I can’t use repeater to boost signal as wire will be buried Concerns I have… It sounds like it could work but have doubts. Can I take Analog to digital and back and have it work. Can anyone with experience with something like this provide advice. Do you think this would work? Thanks for your suggestions and help, Frank G.
Dear, I have a Crasher where a software company has provided software to record mining work and as now they need to be installed 2 cameras to take pictures of Truck one of number plate and second of under Truc to get pictures what is in it, Software company said that he need 2 cameras with 2 different IP and told me to buy CP Plus UNC Series Orange Colour 2 MP camera and POE switch, Can you please help me is it possible with these 2 things if yes how it's possible.
Hello! In this topic I would like to share my impressions of the wireless camera. Perhaps my review will be useful. This is a simple device for solving not complicated tasks. I bought this camera to install near to the entrance door and see what happens there. I chose and watched various devices for a long time, expensive and cheap. From the very beginning I was not sure which camera I needed. Therefore, to experiment purchased a wireless camera on Amazon. I decided not to buy the cheapest device and focused on the reviews and their number. The requirements were as follows: - wifi connection - write to USB flash drive - ability to connect to the registrar if required - metal case - night lights - easy setup and installation SPECS: Sensor: 1/3 "SC1235 CMOS Processor: HiSilicon Hi3518Ev200 Minimum level of illumination: 0.1 Lux @ (F2.0, AGC ON), 0.01 Lux with IR Frame rate: 15 fps (main stream) Lens: 3.6mm Compression Format: H.264 IR LED: 24 LEDs IR illumination range: 20m Power supply: DC12V, 1A Temperature range: -20 - 80 С Protection Level: IP66 Body Material: Metal Viewing angle (according to the formula a = 2arctg (d / 2f)): 74 degrees Wired interface: 1 RJ45 10 m / 100 m Wireless Interface: Realtek RTL8188ETV (802.11bgn) Equipment: - ip-camera; - power supply 12V / 1A (length 3 meters); - removable wifi antenna; - mounting kit with a template and hex; - UTP cat5e 4x2 AWG24 patch cord (1 meter long). Below you can see a compartment for installing a microSD flash card. The compartment is closed with a lid on two screws. Swivel bracket, I would say classic. The camera can be rotated at different angles and fixed as needed. A black overlay is attached to the visor to prevent stray light from the IR LEDs. Personally, I would prefer a black paint spraying, instead of a visor, which over time can fall off and it happens. Wiring harness is very standard for such devices: RJ45 8p8c jack, DC12V power jack and camera reset button. To reset the settings, it is enough to apply power to the camera, wait until it is fully turned on and hold the button down for 5 seconds. SOFTWARE Remote access to the camera works thanks to p2p technology. For connection to a camera from a PC on Windows, the manufacturer offers the program AVSS PC client. The process of adding a camera is the same as in the CMS application, however AVSS immediately finds the camera via the media port, and in the CMS you need to add the camera manually. Finally, the last application you need to say is mobile. ZOSI is betting on it as an easy and effective way to interact with the camera. We need the program Zosi Smart App. The name is the same in both app stores for known platforms. I tested it for android. The process of adding a camera is very simple and is described in detail in the instructions. To be able to view remotely, not from the home LAN, you need to register, however, the confirmation code may not arrive in the mail the first time. I came at the second attempt. After searching and adding a camera, the program requires you to change the standard password to your own and we get to the main window VIDEO QUALITY Image quality is expected for a camera whose resolution is still closer to 1Mp. There are not enough stars from the sky, which means that the range of tasks for such a device will be more than trivial, for example, overview functions: materials brought to your object or not yet, whether your employee went to work or not, is your shovel at the fence or is it up your neighbor, watching an older man / child. In general, the simplest household tasks without frills and claims for serious video surveillance. PROS AND CONS + wifi + write to USB flash drive + onvif support, which means that a ip camera can connect to any NVR + long power cord + looks serious, the neighbor is jealous. - no poe - clumsy mobile software - there is no web interface These and other photos you can see at google drive Made a simple video with day and night shooting I will also answer your questions about the camera.
